Description
GENERAL PROPERTIES
- PLC Screen
- Front Milling
- Gluing Unit
- Preheater
- Speed (8-12 m / min)
- Head-End Cutting
- Bottom-Top Milling
- Corner Rounding
- Radius Scraping
- Cleaning Liquid Spray
- Polishing Units.
TECHNICAL SPECIFICATIONS
- Current: 40 A
- 8-12 meters banding capacity in 1 minute
- Band Thickness: 0.4 – 3 mm
- Workpiece Thickness: 8 – 45 mm
- Pallet Motor Power: 3 KW
- Power: 8 KW
- Motor Power: 0.37 kw
- Air Pressure: 6 bar
- Glue Chamber Capacity: 4 lt
- Glue Heating Time: 15-18min
- Front Milling Motor: 2 × 2.2 KW 12.000 rpm
- Head End Motor: 2 × 0.45 KW 10,500 rpm
- Milling Motor: 2 × 0.45 KW 10,500 rpm
- Corner Rotation Motor: 2 × 0.45 KW 10,500 rpm
- Electricity: 380-400V, 50-60hz, 3 phase
- Machine Length: 6330 mm
- Machine Width: 875 mm
- Machine Height: 1700 mm
- Machine Weight: 1800 kg
